Trijama laminar work stations are designed and manufactured to provide economic solution to have controlled contamination environment in the clean room. LAF work stations are manufactured in Horizontal flow and vertical flow types. TFIPL can supply table top mounted LAF work stations to reduce the cost without affecting the performance. LAF work stations are manufactured as per customer requirement in MS / GI Powder coated and SS.
Trijama Air showers are designed and manufactured to remove contamination from man and materials entering clean room With high air velocity at more than 600 ft/min. The contaminated air filtered and Re-circulated through 2 stages of filters i,e Fine filters and HEPA filters. Air shower’s size and capacity can be designed and supplied as per Customer requirement in MS / GI Powder coated and Stainless Steel -316, 304.
TFIPL-Dispensing/ Sampling booth provides safe and controlled working environment for general dispensing and sampling applications protecting the operator and ensuring that no dust can escape to contaminate the surrounding environment. All respirable and suspended dust particles are pushed down by clean air through HEPA filters. A negative pressure is created at the bottom near Pre filters by exhausting a portion of supply air through exhaust HEPA filters which ensures all the dust particles are passing through filters without escaping to surrounding environment. Any sizes and capacities can be designed and supplied as per customer requirement. Material of construction : SS-316. SS-304.
Soft wall Clean rooms provide an economical, versatile solution to clean manufacturing requirements anywhere you need clean areas. It is low-cost contamination control area, creating an ISO 5 to ISO 8 environment. Modular Clean rooms are widely used in food, electronics, semiconductor, pharmaceutical, biotechnology, nanotechnology and other high technology industries. This modular clean rooms are supplied with Fan filter modules mounted on the top of clean room roof without connecting to the ceiling of the room. These clean rooms are Portable, expandable, and easy to assemble/disassemble. They may be easily relocated when application requirements change. We can offer a range of soft wall clean rooms to meet various construction, dimensional and cleanliness class requirements.
TFIPL manufacture and supply Garment cabins to protect clean room dresses from outside dust contaminations. These Garment cabins are fabricated in Stainless steel and GI. Powder coated materials. The doors are made from unbreakable Polycarbonate see through glasses. Mobile Garment cabinets are also available. Dynamic Garment cabins with re circulated filtered air also can be supplied. UV light is an optional.
Air curtains are aero Dynamically designed for air blowers generating a laminar stream of air with sufficient quantity and speed to offer the desired environment protection through open doorways. Uniform air flow from top throughout the length of the Door opening ensures perfect barrier to the entry of cross contamination. Air curtains are available in metalic powder Coated bodies or in Plastic molded bodies. Available sizes 3, 4 and 5 ft.
Trijama Pass boxes are manufactured in single skin or double skin with puf insulation. Materials can be transferred from one area to another area through pass boxes safely with the door inter-locking system provided to the doors. Pass boxes are available in models Static and Dynamic. Dynamic Pass boxes are provided with inbuilt air shower to remove the contamination from the material passing through the pass box with re-circulated HEPA filtered air. Pass boxes are made in MS Powder coated with SS inner skin and SS both inner and outer skin.
Trijama Operation Theater(OT) Hepa Pleanum are designed and manufactured in single skin or Double skin panels with extruded Aluminium sections. Trijama OT Pleanum is leak proof which completely eliminates contaminations entering in operation theater area. Hepa filters with efficiency 99.997% to 0.3 micron are fitted in OT pleanum. DOP port and pressure ports are provided for testing the leakages and pressure drop across the filters. The filtered air is diffused through perforated grills in laminar flow - uniformly all the area. Grills are provided in Aluminium or SS as per customer requirement.
OT pleanum is manufactured in Aluminium powder coated or SS-304 / 316.
Options:
→ UV Light
→ Provision for fixing light pendant in the middle of the Pleanum
→ Extra light fitting in the sides
→ Installation around pleanum boxes
Trijama Air Handling Units(AHUs) are manufactured in single Skin or puf insulated Double Skin panels with Aluminium extruded supporting frame. Trijama AHUs are compact and rigid in construction. AHUs filter mounting frames are perfactly match with filter flanges to avoid leakages. All the AHUs are leak tested before dispatch.
Terminal boxes are fabricated from CRCA /GI /Aluminium Powder coated, and SS-304 / SS-316. These terminal boxes are available with filter bottom mounted, side mounted or top mounted types. Terminal boxes are supplied with DOP port, Pressure port and suitable perforated grills and volume control dampers.
Terminal boxes filter mounting frame is perfectly matched with filter flanges to ensure 0% leakages.
Options:
→ With Volume Control Tamper
→ With Aluminium SS - grills
Trijama clean room doors are fabricated by CNC mchines in double skin sheets with PUF insulation or Honeycomb Paper Pad in fill with and Poly-Carbonate see through windows. The perfect matching of doors control cross contamination reduces sound level. The doors attached with drop seal at the bottom to control cross contamination of air.
Clean room windows are manufactured with double layer Poly-Carbonate unbreakable see through sheets to eliminate cross contamination of air. It also acts as Sound barrier. MOC - GI Powder coated and SS.
As per pollution control norms, pollutants Contaminants generated in the Industries cannot be directly exposed to the atmosphere. Re usable choked filters shall be cleaned in safe and controlled Cleaning systems. TFPL provides the best solution by manufacturing and supplying filter cleaning system comprises of filter cleaning chamber connected to Dust collector. The dust collector collects all dusts and exhausts out clean air. This system can be installed inside the room. It is essential for Pharmaceutical Industry to have this system to support and bring Green environment. This system can be supplied in SS and GI Powder coated.
